Features
- Pump casing and cover molded from virgin, homogeneous thermoplastic.
- Dynamically balanced, closed vane thermoplastic impellers with molded-in stainless steel inserts assure rigidity, and are key locked to the shaft.
- Stainless steel, large diameter shaft with wet end completely isolated from fluid contact by non-metallic sleeving.
- Pump accommodates standard single and double mechanical seals without modification. Seals are reverse mounted with non-metallic seal component inboard to avoid any metal-to-fluid contact, making it unnecessary to use costly high alloy or exotic metals.
- Metal armor totally encloses thermoplastic casing and flanges to provide nozzle loadings comparable to those of metal pumps.
CHEM-GARD® CGC PUMP DIMENSIONS: INCHES (MM)
| PUMP SIZE | SUCTION SIZE |
DISCHARGE SIZE |
DIMENSIONS IN INCHES (MM) | ||||
| D | X | Y | Z | HA* | |||
| CG-200 | 1 (25.40) |
1 (25.40) |
5 1/4 (133.35) |
6 7/8 (174.24) |
3 1/2 (88.90) |
2 1/2 (63.50) |
12 (304.80) |
| CG-300 | 1 1/2 (38.10) |
1 1/2 (38.10) |
5 1/4 (133.35) |
8 (203.20) |
4 1/2 (114.30) |
3 9/32 (83.31) |
12 (304.80) |
| CG-500 | 2 (50.80) |
1 1/2 (38.10) |
5 1/4 (133.35) |
8 (203.20) |
5 (127.00) |
3 9/32 (83.31) |
12 (304.80) |
| CG-800 | 2 (50.80) |
1 1/2 (38.10) |
5 1/4 (133.35) |
7 15/16 (201.68) |
4 15/16 (125.48) |
3 9/32 (83.31) |
12 (304.80) |
| CG-1200 | 3 (76.20) |
2 (50.80) |
5 1/4 (133.35) |
10 3/4 (273.05) |
7 (177.80) |
4 3/16 (106.43) |
12 (304.80) |
| CG-1800 | 4 (101.60) |
3 (76.20) |
5 1/4 (133.35) |
10 3/4 (273.05) |
7 (177.80) |
4 3/16 (106.43) |
12 (304.80) |
| CG-2400 | 6 (152.40) |
4 (101.60) |
10 1/4 (260.35) |
16 (406.40) |
12 (304.80) |
Centerline Discharge |
15 (381.00) |
Dimensions and specifications subject to change and may vary slightly with motor manufacturer selected.
60- and 50-Hertz performance curves and metric dimensions are available on request.
For higher horsepower and operating speeds consult factory.
Catalog sheets available on other Vanton centrifugal pump models including self-priming designs,
vortex heads, magnetic drive and foot-mounted pumps.
